Dump truck
Product Description:
- Superior Off-Road Capability
- Equipped with rubber tracks, it delivers strong traction and low ground pressure. It easily navigates mud, sand, mountainous terrain, steep slopes, and rough ground without slipping or getting stuck.
- Excellent Terrain Adaptability
- The compact body and small turning radius allow flexible operation in orchards, farms, construction sites, greenhouses, and narrow country lanes.
- Stable & High Load Capacity
- Boasts a large payload relative to its size. The tracked design ensures stability during heavy-load travel, preventing tipping or nose-diving. Ideal for short-haul transport of soil, sand, gravel, seedlings, and crops.
- Powerful Climbing Performance
- High tractive force enables it to handle steep mountain roads and slopes with ease. It works reliably on gradients where wheeled vehicles cannot pass.
Product Details
| Technical Parameters | |
| Engine | |
| Parameter | Value |
| Engine Model | BLT New Pioneer 200 |
| Engine Type | Single cylinder, OHV, 4-stroke, air cooling |
| Displacement | 203CC |
| Rated Power | 6.5HP/3600rpm |
| Fuel Type | 92 # Gasoline |
| Fuel Consumption | ≤0.395 g/kw·h |
| Fuel Tank Capacity | 3.6 L |
| Engine Oil Capacity | 0.6 L |
| Weight | |
| Parameter | Value |
| Total Weight | 414 KG |
| Max Loading Weight | 500 KG |
| Machine Size (Without pedal, without bucket) | 1570*880*1300 MM |
| Overall Size with Foot Pedal & Bucket | 2050*880*1300 MM |
| Container Size | 1050*730*730 MM |
| Chassis Width | 730 MM |
| Track data | |
