Tracked firefighting robot
Product Description:
- Remote Intelligent ControlWireless remote operation with real-time video transmission, allowing operators to work far away from dangerous fire scenes.
- Strong Fire Suppression CapacityEquipped with high-power fire water cannon, support adjustable water flow and angle, fast and accurate fire extinguishing.
- All Terrain AdaptabilityCrawler walking design, stable climbing and crossing obstacles, suitable for complex road conditions of various fire sites.
- High Temperature And Explosion ProofAdopt high temperature resistant and explosion-proof structure, can work stably in harsh high-temperature and smoky environment.
- Multi-function Integrated DesignBuilt-in temperature detection, smoke monitoring and obstacle avoidance system, one machine meets fire rescue, patrol monitoring and emergency disposal needs.
Product Details
This fire fighting robot is an intelligent unmanned fire rescue equipment, equipped with high-pressure fire water cannon and all-terrain walking system.It can be remotely controlled to enter high-temperature, smoky, flammable and explosive dangerous areas instead of manual firefighters.The robot realizes real-time image transmission, precise water spray, temperature detection and obstacle avoidance.It is widely used in chemical plants, oil depots, warehouses, tunnels, large buildings and industrial parks for fire monitoring and emergency fire suppression.
Specifications
| CHASSIS CONFIGURATION PARAMETER | |||
| Parameter | Value | Parameter | Value |
| Overall Dimensions (L x W x H) | 1400*850*1000mm | Chassis Structure | Shock-absorbing walking*2 |
| Chassis Motor Power | 48V DC brushless motor, 1.5kW * 2 | Water Jet Model | PSKDY60 |
| Battery | 48V 52A lead-acid battery | Rated Working Pressure | 1.2MPa |
| Wireless Remote Control Radius (M) | 1000m | Rated Flow Rate | 60LS |
| Wireless Gimbal Camera | 360° | Maximum Range (Water/Foam) | 75/65≥M |
| Walking Speed | 0-3km/h | Maximum Spray Angle | ≥90° |
| Image Transmission Distance | 0-1000m | Pitch Angle | -30° ~ +70° |
| Remote Control | Visually visible | Horizontal Rotation Angle | ≥90° |
